Smart Visoglide Plus Patio

Visoglide Plus offers the same contemporary styling and robust performance associated with the system whilst delivering superior thermal performance.

Premium Performance

This adaptable system is suitable for use as either sliding commercial entrances where large opening apertures are required, or as dynamic residential sliding doors that maximise light and give stunning unimpeded views.

Visoglide Plus profiles have been designed to improve both strength and weather resistance. All main sections feature an extended polyamide thermal break that allows Visoglide Plus to achieve a U Value of 1.6 W/m²K when installed with a suitable sealed unit.

  • Inline sliding or lift & slide options

  • Slim interlock option

  • Colour matched accessories available

  • British Standard Kitemarked system achieving: KM 530838 PAS 24:2012



Dimensions and Performance

  • Sliding Door Max Width: Within height & weight limitations

  • Sliding Door Max Height: 2500mm (Sash)

  • Sliding Door Max Weight: 250kg

  • Glazing: 28 Standard, 38mm glazed unit option available

  • Frame Depth: 100mm

  • Typical Sightlines: 117mm (Outer frame), 83mm (Interlock)

  • 1.6 W/m²K based on using a sealed unit with 1.0 W/m²K centre pane

  • BS Kitemarked to BS 6375-1:2009

  • PAS24 Available

Download Brochure


Colour & Finishes

Across our range of products there are hundreds of colours to choose from, you can match your aluminium doors and windows to your worktops, furniture, or anything you like. Pick from over 200 RAL colours, or a vast array of finishes including 5 carefully curated collections from Smarts - Sensations, Cotswold, Alchemy, Naturals and Creations. Plus, because they’re powder-coated, durability is never an issue. The colour is baked-on, providing a lasting finish that won’t peel off or lose its colour – and is guaranteed for 25 years.
